| Brand | : | ACE |
| Cylinder | : | 4 |
| HP Category | : | 61HP |
| Gear | : | 8 Forward + 2 Reverse |
| Brakes | : | Mechanical/Oil Immersed Brakes |
| Warranty | : | N/A |
| Price | : | ₹ 9.97 to 10.38 L |
ACE DI-6565
Ace Tractor 6565 comes with the facility of Oil Immersed Brakes. The special feature of Ace 6565 is its lifting capacity of 1800 and also comes with single power take off.
Ace 6565 is a 60 HP Tractor. Ace Tractor 6565 comes with 4 powerful cylinders capable of a good working in fields.
ACE DI-6565 Full Specifications
ACE DI-6565 Engine
| No. Of Cylinder | : | 4 |
| HP Category | : | 61 HP |
| Capacity CC | : | 4088 CC |
| Engine Rated RPM | : | 2200 RPM |
| Air Filter | : | Dry type with air cleaner with clogging system |
| PTO HP | : | 52 HP |
| Cooling System | : | Water Cooled |
ACE DI-6565 Transmission(GearBox)
| Clutch Type | : | Dual Clutch |
| Gear Box | : | 8 Forward + 2 Reverse |
| Battery | : | 12 V 88 AH |
| Alternator | : | 12 V 42 A |
| Forward Speed | : | 2.92 - 35.1 kmph |
| Reverse Speed | : | 3.62 - 14.3 kmph |
ACE DI-6565 Brakes
| Brake Type | : | Oil Immersed Brakes |
ACE DI-6565 Steering
| Steering Type | : | Power Steering |
ACE DI-6565 Power Take Off
| PTO Type | : | Mechenical actuatad hand operated |
| PTO rpm | : | 540 |
ACE DI-6565 Fuel Capacity
| Fuel Tank Capacity | : | 65 litre |
ACE DI-6565 Dimension and Weight
| Weight | : | 2280 KG |
| Wheelbase | : | 2130 MM |
| Overall Length | : | 3845 MM |
| Tractor Width | : | 1940 MM |
| Ground Clearance | : | 465 MM |
ACE DI-6565 Lifting Capacity(Hydraulics)
| Lifting Capacity in Kg | : | 1800 kgs |
| 3 point Linkage | : | Automatic Depth and Draft Control, Live Hydraulics with Mix Modes |
ACE DI-6565 Tyre Size
| Front | : | 7.50 x 16 |
| Rear | : | 14.9 x 28 / 16.9 x 28 |
ACE DI-6565 Additional Features
| Accessories | : | Toplink, Tool, Drawbar, Hitch, Hook |
| Status | : | Launched |
